CEMB USA C73-L SE (B) - Manual

I 0730_0731 - 11/09 - Rev. B
Use and maintenance manual GB
ENGLISH
General Index
1. FOREWORD 3
1.1 GENERAL 3
1.2 PURPOSE OF THE MANUAL 3
1.3 WHERE AND HOW TO KEEP THE MANUAL 3
1.4 MANUAL UPGRADES 3
1.5 COLLABORATION WITH USERS 4
1.6 MANUFACTURER 4
1.7 MANUFACTURER'S RESPONSIBILITY AND WARRANTY 4
1.7.1 TERMS OF WARRANTY 4
1.8 TECHNICAL ASSISTANCE SERVICE 5
1.9 COPYRIGHT 5
2. TECHNOLOGICAL DESCRIPTION 6
2.1 PURPOSE 6
2.2 TECHNICAL SPECIFICATIONS 6
2.3 DIMENSIONS AND WEIGHTS 6
3. STARTING 7
4. CONTROL PANEL AND COMPONENTS 10
4.1 AUTOMATIC DISTANCE AND DIAMETER GAUGE 10
4.2 AUTOMATIC WIDTH GAUGE (OPTIONAL) 10
5 USE OF THE WHEEL BALANCER 11
5.1 INITIAL SCREEN 11
5.1.1 SCREEN-SAVE SCREEN 11
5.2 PRESETTING OF WHEEL DIMENSIONS 11
5.2.1 Automatic presetting ( also CORRECTION MODE) 11
5.2.1.1 Standard wheels 11
5.2.1.2 Automatic width measurement (optional ) 12
5.2.1.3 ALUS wheels 13
5.2.2 Manual presetting 13
5.3 USER CONTROL 14
5.3.1 To save USER 14
5.3.2 To call USER 14
5.4 RESULT OF MEASUREMENT 14
5.4.1 Indication of exact correction weight position 15
5.4.2 “SPLIT” control 15
5.4.3 Automatic minimization of static unbalance 16
5.5 WHEN AND WHY MATCHING 16
5.5.1 Presetting of tolerance on the machine 17
5.5.2 Value of static unbalance, correlated with eccentricity 17
5.5.3 Value of unbalance corresponding to eccentricity 17
5.6 ECCENTRICITY MEASUREMENT (OPTIONAL) 17
5.6.1 Eccentricity optimisation 18
6. MENU 19
