I 0201 GB- 17
5.5.1 - INDICATION OF EXACT CORRECTION WEIGHT POSITION
It is recommended to always use this function when correcting the unbalance through adhesive weights:
ALU S, STATIC, ALU 2, ALU 3.
In all cases this function allows cancelling approximations in the mounting of counterweights with
consequent reduction of the residual unbalance.
- Press button
7
from the Measurements screen.
- Pull out the rim distance+diameter gauge in position A, fi gure 8. Approach of the weight to the
correction position is indicated by a moving coloured arrow [
].
- When a fi xed arrow [
] is reached, rotate the wheel to correction position (FI or FE) and apply
the counterweight by turning the tip of the gauge towards the outside, into the position in which the
pincers touches the wheel. Compensation is made for the fact that the weight application position is
no longer at 12 o’clock (fi g. 11).
When the acoustic signal is enabled (see 6.8), the reaching of a fi xed arrow [
] is accompanied
by a “beep”.
Fig. 11
