CEMB USA ER100 (A) - Manual

I 0902 - 11/10 - Rev. A
ENGLISH
Use and maintenance manual EN
General Index
1. FOREWORD 3
1.1 GENERAL 3
1.2 PURPOSE OF THE MANUAL 3
1.3 WHERE AND HOW TO KEEP THE MANUAL 3
1.4 MANUAL UPGRADES 4
1.5 COLLABORATION WITH USERS 4
1.6 MANUFACTURER 4
1.7 MANUFACTURER’S RESPONSIBILITY AND WARRANTY 4
1.7.1 Terms of warranty 4
1.8 TECHNICAL ASSISTANCE SERVICE 5
1.9 COPYRIGHT 5
2. INSTALLATION 6
3. MACHINE DESCRIPTION 10
3.1 MACHINE FUNCTION 10
3.2 TECHNICAL SPECIFICATIONS 11
3.3 DIMENSIONS AND WEIGHTS 11
3.4 WARNINGS 11
4. WHEEL LIFTING 14
5. WHEEL LOCKING 15
6. USE OF THE WHEEL BALANCING MACHINE 16
6.1 DIMENSION ACQUISITION 16
6.2 CORRECTION MODE SELECTION 17
6.3 UNBALANCE UNIT OF MEASURE SELECTION 18
6.4 UNBALANCE MEASUREMENT (FIRST SET OF BUTTONS) 19
6.4.1 Spindle rotation lock/release 19
6.5 UNBALANCE MEASUREMENT (SECOND SET OF BUTTONS) 20
6.6 THRESHOLD DISPLAY 21
6.7 UNBALANCE CORRECTION 22
6.7.1 Iron rims 22
6.7.2 Aluminium rims 23
6.7.3 Change weight application distance 24
6.8 UNBALANCE SPLIT 25
6.9 UNBALANCE OPTIMISATION 26
6.10 TYRE SET 27
6.10.1 Tyre set value certifi cate 29
6.10.2 Tyre set certifi cate customisation 29
6.11 WEIGHT STATISTICS 30
6.12 BALANCING CERTIFICATE PRINTOUT 32
6.12.1 Balancing certifi cate customisation 33
6.13 SCREENSAVER 36
