I 0201 GB - 12
- Wheel ALU-S (correction from the inside for two balancing planes with direct calibration):
After the measurement carried out for the inside FI as described in fi g. 9, pull out the gauge further to
memorize the data for the outside FE: select position A or B in fi gure 8 as required; keep this position
for at least 2 seconds.
The counterweight symbols change colour.
When the acoustic signal is enabled (see ACUSTIC SIGNAL ), the acquisition is accompanied by a
“beep”.
The following buttons are enabled:
5 The button LT (LIGHT TRUCK) serves for improved dimensional calibration of large
size wheels such as off-the-road vehicles, trucks, or wheels which project by a large
amount from the rim.
Press button LT after the distance measurement and immediately upon lowering the
wheel guard for width measurement. The optional feature is automatically disabled
upon measuring another wheel.
6 Select the dimensions presetting in manual mode screen.
7 /
STOP
Return to initial screen.
START
Balancing spin
5.3.2 TO CALL MEMORIZED MEASUREMENTS
1 / 2 / 3 / 4 Press the button with relative user’s name.
- when 1 is pressed, the stored measurements will be called
(USER MEMORIZATION) while disregarding other measurements
made in the meantime.
- when 2 is pressed, the currently preset dimensions are saved.
Fig. 9
