Climax BB3000 Facing Head Accessory - Manual

bb3000 Facing head accessory
For the bb3000 Portable boring Machine
The facing head for the BB3000 Boring
Machine is quick to set up and easy to use.
Face from 2 - 7 inches (50.8 - 177.8 mm) in
diameter, or from 2 - 10 inches (50.8 - 254.0
mm) in diameter with the longer leadscrew
set.
The facing head needs only 3.7 inches
(94.0 mm) of clearance from the surface
being faced to mount to the bar and oper-
ate.
■ Simple to set up and use.
■ Lightweight, only about 9 lbs
(4.1 kg).
■ Faces 2 - 7 inches (50.8 - 177.8 mm) in
diameter, swings within a 7.25 inch (184.2
mm) diameter.
■ Optional leadscrew set faces
2 - 10 inches (50.8 - 254.0 mm) in diame-
ter, swings
within a 10.25 inch (260.4 mm) diameter.
■ Fixed feed rate of 0.005
(0.127 mm) per revolution.
■ Bi-directional operation.
Ordering Information
31412 Facing Head Assembly
2013
BB3F
09
