Technical Information
• The feed rate is infinitely adjustable and
reversible from 0.0 to 0.664
inches (0.0 to 17 mm)/minute.
• Rapid Advance is available using your
hand drill and a 7/16 inch (11 mm) drive
socket (included). Typical rapid feed
rates using your 0 - 400 RPM drill is 0.0
- 32 inches (0.0 - 813 mm)/min.
• Power requirements: 120/240V, 4A,
50/60Hz.
• The Climax Electric Axial Feed is also
available to fit competitive boring
systems.
Rotational drive
assem
bly
Boring bar/lead
screw assembly
Tool carrier assembly
Hydraulic motor
Adaptor feed axial assembly
Feed axial assembly
climax electric axial feed assembly
shown mounted to a
climax bb8100 boring machine
End mount sup-
port assembly
Tools head assembly
(manual assembly shown)
ID mount bearing
support assembly
