S98 O & M : 9
Series 98 Operation & Maintenance
ITEM DESCRIPTION MATERIAL QTY .
33 Piston Ductile Iron 1
34 End Cap, Pressure Module Ductile Iron 1
35 Piston Rod Alloy Steel 1
36 ** Bushing (Adaptor) PTFE Bronze 2
37 * Seal, U-Cup Buna-N 1
38 Split Collar Alloy Steel 4
39 Tie Rod Steel 4
40 Locknut, Nylok Steel 4
41 * O-Ring (Piston Rod) Buna-N 1
42 * Wear Ring PTFE 2
43 * Quad Seal Buna-N 1
44 * O-Ring (Barrel) Buna-N 2
45 Retainer Ring Stainless Steel 1
46 Pipe Plug Carbon Steel 1
47 Adaptor, Spring Module Carbon Steel 1
48 Pipe Carbon Steel 1
49 End Cap, Spring Module Carbon Steel 1
50 Spring Guide Carbon Steel 1
51 Button Plastic 9
52 Spring, Compression Alloy Steel 1
53 Lifting Lug Carbon Steel 1
54 Spring Rod Alloy Steel 1
55 End Cover Carbon Steel 1
56 Retainer Ring Stainless Steel 1
57 Spring Washer Spring Steel 4
58 Hex Bolt Steel 4
59 * O-Ring (End Cover) Buna-N 1
60 Stud Steel 12
61 Nut Steel 12
62 Spring Washer Spring Steel 12
63 * O-Ring (Module) Buna-N 2
64 Load Ring Carbon Steel 1
* Parts in Seal Kits * / ** Parts in Repair Kits
ITEM DESCRIPTION MATERIAL QTY .
1 Yoke Housing Ductile Iron 1
2 Guide Rod Alloy Steel 1
3 Housing Cover Ductile Iron 1
4 ** Bushing (Yoke) PTFE Bronze 2
5 * O-Ring (Yoke) Buna-N 2
6 * O-Ring (Cover) Buna-N 1
7 Top Cover Ductile Iron 1
8 * O-Ring (Top Cover) Buna-N 1
9 ** Flanged Bushing PTFE Bronze 1
10 * O-Ring (Accessory Drive) Buna-N 1
11 Accessory Drive Stainless Steel 1
12 Hex Bolt Steel 8
13 Spring Washer Spring Steel 8
14 Set Screw, Socket Head Steel 2
15 Dowel Pin Hardened Steel 4
16 Socket Head Caps Screw Steel 4
17 Socket Head Caps Screw, Low Head Steel 1
18 Seal Nut Steel 2
19 Stop Bolt Steel 2
20 Breather Vents Carbon Steel 1
21 Yoke Ductile Iron 1
22 ** Slider Block Bronze 2
23 Yoke Pin Alloy Steel 1
24 Retainer Plate Plastic 2
25 Guide Block Carbon Steel 1
26 ** Bushing (Guide Rod) PTFE Bronze 2
27 ** Bushing (Yoke Pin) PTFE Bronze 2
28 Cap Screw, Flat Head, Hex Socket Steel 8
29 Position Indicator Plastic 1
30 Cap Screw, Flat Head, Hex Socket Steel 1
31 Adaptor, Pressure Module Ductile Iron 1
32 Barrel Carbon Steel 1
For reference only. Please refer to ES drawing for current information.
