S98 O & M : 15
Series 98 Operation & Maintenance
NOTICE
Actuator Designation needs to be suitably changed (from FCW
to FCCW or vise versa) on the name plate, after completing this
configuration change
.
7.2 Double Acting to Spring Return
a Spring Module will need to be mounted opposite the
Pressure Module with a Module Mounting Kit.
remove the Pressure Module from the actuator. Follow the
shifting the Pressure Module is not required.
00020 – DA Assembly).
Module Adaptor Plate, applying thread lock compound on
the threads. Install the module O-ring in adaptor groove.
for proper valve seating.
the Pressure Module and replace the connector with a
the Adaptor port.
NOTICE
Actuator Designation needs to be suitably changed and
Maximum Operating Pressure of the actuator to be suitably
updated on the name plate, after completing this configuration
change.
7.3 Spring Return to Double Acting
Cover Kit.
Module and connect suitable connector for connecting the
air line from the direction control valve.
NOTICE
Actuator Designation needs to be suitably changed and
Maximum Operating Pressure of the actuator to be suitably
updated on the name plate, after completing this configuration
change.
