S98 O & M : 23
Series 98 Operation & Maintenance
11.0 Maximum Operating Pressure (cont.)
11.4 Spring Return (Bar)
MAXIMUM OPERATING PRESSURE FOR SPRING RETURN ACTUATOR - Symmetrical Yoke / Canted Yoke
Model
Rated Torq
Cyl Size
Pressure, bar
S1
S2
S3
S4
S5
Nm
Lb-in
S
C
S
C
S
C
S
C
S
C
45 E2
4500
39830
P08
10.3
10.3
10.3
10.3
10.3
10.3
P09
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
P10
10.1
8.6
10.3
9.3
10.3
10.2
10.3
10.3
P12
7.0
6.0
7.4
6.4
8.1
7.1
8.4
7.4
P14
5.1
4.4
5.5
4.7
5.9
5.2
6.1
5.4
73 E2
7300
64612
P10
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
P12
9.6
8.3
9.9
8.6
10.3
9.2
10.3
9.7
P14
7.0
6.1
7.3
6.3
7.7
6.7
8.1
7.1
P16
5.4
4.6
5.5
4.8
5.9
5.1
6.2
5.4
14 E3
14000
123914
P12
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
P14
10.3
9.5
10.3
9.8
10.3
10.2
10.3
10.3
10.3
10.3
P16
8.4
7.2
8.7
7.5
9.0
7.8
9.5
8.3
9.9
8.7
P18
6.6
5.7
6.8
5.9
7.1
6.1
7.5
6.6
7.8
6.8
P20
5.4
4.6
5.5
4.8
5.7
5.0
6.1
5.3
6.3
5.5
24 E3
24000
212424
P14
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
P16
10.3
9.5
10.3
10.0
10.3
10.3
10.3
10.3
10.3
10.3
P18
8.7
7.5
9.1
7.9
9.6
8.4
10.0
8.8
10.3
9.2
P20
7.0
6.1
7.3
6.4
7.8
6.8
8.1
7.1
8.4
7.4
P22
5.8
5.0
6.1
5.3
6.4
5.6
6.7
5.9
6.9
6.1
P24
4.9
4.2
5.1
4.4
5.4
4.7
5.6
4.9
5.8
5.1
45 E3
45000
398295
P18
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
10.3
P20
10.3
9.2
10.3
9.5
10.3
10.2
10.3
10.3
10.3
10.3
P22
8.8
7.6
9.1
7.9
9.6
8.4
9.9
8.7
10.3
9.0
P24
7.4
6.4
7.6
6.6
8.1
7.0
8.3
7.3
8.6
7.6
P28
5.4
4.7
5.6
4.8
5.9
5.2
6.1
5.3
6.3
5.5
