S98 O & M : 22
Series 98 Operation & Maintenance
11.0 Maximum Operating Pressure (cont.)
11.3 Spring Return (PSI)
MAXIMUM OPERATING PRESSURE FOR SPRING RETURN ACTUATOR - Symmetrical Yoke / Canted Yoke
Model
Rated Torq Cyl Size
Pressure, psi
S1 S2 S3 S4 S5
Nm Lb-in S C S C S C S C S C
45 E2 4500 39,830
P08 150 150 150 150 150 150
P09 150 150 150 150 150 150 150 150
P10 146 125 150 135 150 148 150 150
P12 101 87 108 93 117 103 121 107
P14 74 63 79 69 86 75 89 79
73 E2 7300 64,612
P10 150 150 150 150 150 150 150 150
P12 139 120 144 125 150 133 150 141
P14 102 88 105 91 111 98 117 103
P16 78 67 80 70 85 75 90 79
14 E3 14000 123,914
P12 150 150 150 150 150 150 150 150 150 150
P14 150 137 150 142 150 148 150 150 150 150
P16 122 105 126 108 130 113 138 121 143 126
P18 96 83 99 86 103 89 109 95 113 99
P20 78 67 80 69 83 72 88 77 91 80
24 E3 24000 212,424
P14 150 150 150 150 150 150 150 150
P16 150 138 150 145 150 150 150 150 150 150
P18 126 109 132 114 139 122 145 127 150 133
P20 102 88 106 92 113 99 117 103 122 108
P22 84 73 88 76 93 81 97 85 101 89
P24 71 61 74 64 78 68 81 71 84 75
45 E3 45000 398,295
P18 150 150 150 150 150 150 150 150 150 150
P20 150 134 150 138 150 147 150 150 150 150
P22 128 110 132 114 139 122 144 126 149 131
P24 107 93 111 96 117 102 120 105 125 110
P28 79 68 81 70 86 75 88 77 91 80
