preliminary checkout.
Execution error. Command parameter overflows or the condition is not right.
Command error. Syntax or semantic error occurs when receiving information.
Power on. It is 1when power supply is reset.
3
5
6
7
QUES
ESB
MSS
RQS
OPER
Status byte register
If a quest enable condition changes, QUES is 1.
If a standard event status enable register changes, ESB is 1.
If a operation event enable register changes, OPER is 1.
Structure of condition register:
Quest condition register
condition event enable
OV
OT
Unr
n.u.
n.u.
n.u
n.u
n.u
Operation event register Status byte register
condition event enable event enable
CAL n.u
WTG n.u
CV n.u
CC QUES
RI n.u
n.u ESB
n.u RQS
n.u OPER
Standard event status register
event enable
OPC
n.u
QYE
DDE
EXE
CME
n.u
PON
