17
2 X 100 Steps
1 X 200 Steps
Exit
Out On Timer Output timer. If Timer State is set to ON, power supply output will turn off after the
timer elapsed.
Timer State Setting POWER ON timer state
On Enable Output Timer. Output will turn off after value set
in menu “Timer Set” counted down to zero.
Off< Default >
Timer Set Setting time of POWER ON timer.
Timer= **S
Exit
Exit
3.6.2 Menu Function
ShortCut Recall
This parameter enables a Shortcut version of the Recall functionality available by pressing the Recall button ( see
3.5)
To enable this function, do the following:
1. Press
Shift
+
MENU
When Config is displayed, press
ENTER
2. Press
▲, ▼ to scroll to ShortCut Recall then press ENTER
3. Press
▲, ▼to turn this feature On，press ENTER
to confirm.
4. Press Esc twice to exit from the menu
Now you can conveniently recall up to 9 settings by simply pressing one of the corresponding number keys 1 – 9.
The setting previously stored at that location, (using the Save function), will be retrieved and activated. If the
selected location is empty, EEPROM ERROR will be displayed.
Setting the Baud Rate (>BAUDRATE)
This parameter configures the baud rate for serial communication. Possible values are 4800, 9600, 19200 or
38400. When operating the power supply in remote mode, make sure that you configure identical baud rate
settings for the power supply and the computer. The default setting is 4800.
Setting Address (>ADDRESS)
With this parameter, it is possible to address each instrument. The address range is 0 to 30. The default address
is zero. This is useful when multiple instruments of the same model are connected to a PC for remote
connection. The address is used to identify the instrument to control.
Port Mode
A 4-pin connector in the rear panel is provided for digital input and output signals. For models 9150, 9151,
9152, and 9153, it is a 2-pin connector. This digital port can be configured to provide Fault/Inhibit, External
Trigger or Digital I/O functions. The signal level is TTL.
