7. Print and Update
7.1. Print Data
The Print Data function allows printing out diagnostic data
recorded by the scan tool or customized test reports by
connecting the scan tool to a PC or laptop with the USB cable
supplied.
To print out the retrieved data, you need the followings:
AL609 scan tool
A PC or laptop with USB ports
A USB cable
1) Install the PC Suite through the included CD, or download the
applications in our website:
or our
distributors‟ site.
2) Connect the scanner to the PC with the USB cable supplied.
3) Run Printer software on the PC.
4) Select Playback function in Main Screen of the scan tool.
Select OBDII or ABS from the menu, use the UP/DOWN scroll
button to select the data item you want to print.
5) Wait for the reviewing window to display (Figure 6.3), and then
select Print function at the bottom. The selected file will be
uploaded to your computer. For more detailed instructions,
please refer to 6. Playback.
6) The Printer program interface will show as below.
