Autel Autolink AL609 User Manual
Page 19
17
LCD Test
The LCD Test function checks if the LCD display is working
normally.
1) On System Setup screen, use the UP/DOWN scroll button and
LEFT/RIGHT scroll button to select LCD Test, and press the
OK button.
2) Check if there is any missing spot in the red, green, blue, black
and white LCD displays.
3) When the test is completed, press the ESC button to exit.
About
The About function allows viewing of the important information,
such as serial number and software version number of the scan tool.
1) On System Setup screen, use the UP/DOWN scroll button and
LEFT/RIGHT scroll button to select About. Press the OK
button, and wait for the About screen to appear.
2) View the tool‟s information on the screen. (Figure 3.7) Press the
ESC button to exit.
Figure 3.7
