Model Frequency Range Maximum SWR Power Linearity (1) Maximum Power Connector Type Weight
8485A 50 MHz to 26.5 GHz 50 MHz to 100 MHz: 1.15 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk APC - 3.5mm(m) Net: 0.2 kg (.38 lb)
100 MHz to 2 GHz: 1.10 30 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
2 GHz to 12.4 GHz: 1.15
12.4 GHz to 18 GHz: 1.20
18 GHz to 26.5 GHz: 1.25
Opt 033 50 MHz to 33 GHz 26.5 GHz to 33 GHz: 1.40 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk APC - 3.5mm(m) Net: 0.2 kg (.38 lb)
30 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
8481A 10 MHz to 18 GHz 10 MHz to 30 MHz: 1.40 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk Type - N (m) Net: 0.2 kg (0.38 lb)
30 MHz to 50 MHz: 1.18 30 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
50 MHz to 2 GHz: 1.10
2 GHz to 12.4 GHz: 1.18
12.4 GHz to 18 GHz: 1.28
8482A 100 kHz to 4.2 GHz 100 kHz to 300 kHz: 1.60 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk Type - N (m) Net: 0.2 kg (0.38 lb)
300 kHz to 1 MHz: 1.20 30 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
1 MHz to 2 GHz: 1.10
2 GHz to 4.2 GHz: 1.30
8483A 100 kHz to 2 GHz 100 kHz to 600 kHz: 1.80 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 10 W pk Type - N (m) Net: 0.2 kg (0.38 lb)
(75 ohm) 600 kHz to 2 GHz: 1.18 (75 ohm) Shipping: 0.5 kg (1.0 lb)
R8486A 26.5 GHz to 40 GHz 26.5 GHz to 40 GHz: 1.40 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk Waveguide Flange Net: 0.26 kg (0.53 lb)
30 W.µs per pulse UG-385/U Shipping: .66 kg (1.3 lb)
Q8486A 33 GHz to 50 GHz 33 GHz to 50 GHz: 1.50 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk Waveguide Flange Net: 0.26 kg (0.53 lb)
30 W.µs per pulse UG-385/U Shipping: .66 kg (1.3 lb)
V8486A 50 GHz to 75 GHz 50 GHz to 75 GHz: 1.06 +10 dBm to + 20 dBm: (±2%) 200 mW avg, 40 W pk Waveguide Flange Net: 0.4 kg (0.9 lb)
-30 dBm to + 10 dBm: (±1%) (10.µs per pulse, 0.5% UG-385/U Shipping: 1 kg (2.1 lb)
duty cycle)
W8486A 75 GHz to 110 GHz 75 GHz to 110 GHz: 1.08 (±2%) 200 mW avg, 40 W pk Waveguide Flange Net: 0.4 kg (0.9 lb)
(10.µs per pulse, 0.5% UG-385/U Shipping: 1 kg (2.1 lb)
duty cycle)
8487A 50 MHz to 50 GHz 50 MHz to 100 MHz: 1.15 +10 dBm to + 20 dBm: (±3%) 300 mW avg, 15 W pk 2.4 mm (m) Net: 0.14 kg (.28 lb)
100 MHz to 2 GHz: 1.10 30 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
2 GHz to 12.4 GHz: 1.15
12.4 GHz to 18 GHz: 1.20
18 GHz to 26.5 GHz: 1.25
26.5 GHz to 40 GHz: 1.30
40 GHz to 50 GHz: 1.50
Model Frequency Range Maximum SWR Power Linearity (1) Maximum Power Connector Type Weight
8481B 10 MHz to 18 GHz 10 MHz to 2 GHz: 1.10 +35 dBm to + 44 dBm: (±4%) 0 0 C to 35 0 C: 30W avg (2) Type - N(m) Net: 0.8 kg (1.75 lb)
2 GHz to 12.4 GHz: 1.18 35 0 C to 550 C: 25W avg Shipping: 1.5 kg (3.25 lb)
12.4 GHz to 18 GHz: 1.28 0.01 to 5.8 GHz: 500W pk
5.8 to 18 GHz: 125 W pk
500 W.µs per pulse
8482B 100 kHz to 4.2 GHz 100 kHz to 2 GHz: 1.10 +35 dBm to + 44 dBm: (±4%) 0 0 C to 35 0 C: 30W avg (2) Type - N(m) Net: 0.8 kg (1.75 lb)
2 GHz to 4.2 GHz: 1.18 35 0 C to 55 0 C: 25W avg Shipping: 1.5 kg (3.25 lb)
0.01 to 5.8 GHz: 500W pk
5.8 to 18 GHz: 125 W pk
500 W - µs per pulse
Model Frequency Range Maximum SWR Power Linearity (1) Maximum Power Connector Type Weight
8481H 10 MHz to 18 GHz 10 MHz to 8 GHz: 1.20 +25 dBm to + 35 dBm: (±5%) 3.5 W avg, 100 W pk Type - N (m) Net: 0.2 kg (0.38 lb)
8 GHz to12.4 GHz: 1.25 100 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
12.4 GHz to 18 GHz: 1.30
8482H 100 kHz to 4.2 GHz 100 kHz to 4.2 GHz: 1.20 +25 dBm to + 35 dBm: (±5%) 3.5 W avg, 100 W pk Type - N (m) Net: 0.2 kg (0.38 lb)
100 W.µs per pulse Shipping: 0.5 kg (1.0 lb)
20
8480 Series Sensors (with EPM series power meters)
25 Watt Sensors, 1 mW to 25 W (0 dBm to +44 dBm)
3 Watt Sensors, 100 µW to 3 W (–10 dBm to +35 dBm)
100 mW Sensors, 1 µW to 100 mW (–30 dBm to +20 dBm)
Table 15
