18
Calibration Factor (CF) and Reflection Coefficient (Rho)
Calibration Factor and Reflection Coefficient data are provided at frequency intervals on a data sheet included with the
power sensor. This data is unique to each sensor. If you have more than one sensor, match the serial number on the data
sheet with the serial number on the power sensor you are using. The CF corrects for the frequency response of the sensor.
The EPM series power meter automatically reads the CF data stored in the sensor and uses it to make the corrections.
Reflection Coefficient (Rho) relates to the SWR according to the following formula:
SWR =(1 + Rho)/(1 - Rho)
Maximum uncertainties of the CF data are listed in Tables 13A and 13B. As the E-series E9300 power sensors have two in-
dependent measurement paths (high and low power paths), there are two calibration factor uncertainty tables. The uncer-
tainty analysis for the calibration of the sensors was done in accordance with the ISO Guide. The uncertainty data report-
ed on the calibration certificate is the expanded uncertainty with a 95% confidence level and a coverage factor of 2.
Calibration Factor Uncertainties (Low Power Path) Calibration Factor Uncertainties (High Power Path)
Table 13A Table 13B
General
Dimensions: Length 130 mm, Width 38 mm, Height 30 mm
Weight: 0.18 kg (0.4 lbs)
References:
[1] TIA is the Telecommunications Industry Association; EIA is the Electronic Industries Association.
TIA/EIA/IS-97-A is the Recommended Minimum Performance Standards for Base Stations Supporting Dual-Mode Wideband
Spread Spectrum Cellular Mobile Stations.
TIA/EIA/IS-98-A is the Recommended Minimum Performance Standards for Dual-Mode Wideband Spread Spectrum
Cellular Mobile Stations.
14 GHz to 18 GHz ± 2.0 %
6 GHz to 14 GHz ± 1.8 %
1.2 GHz to 6 GHz ± 1.7 %
500 MHz to 1.2 GHz ± 1.8 %
30 MHz to 500 MHz
(E9304A: 9kHz to 500MHz) ± 1.6 %
10 MHz to 30 MHz ± 1.8 %
Frequency Uncertainty (%)
(25 0C +10 0C) Uncertainty (%)
(0 to 55 0C)
± 2.2 %
± 2.0 %
± 2.5 %
± 2.0 %
± 2.0 %
± 2.2 %
Frequency Uncertainty (%)
(25 0C +10 0C)
10 MHz to 30 MHz
30 MHz to 500 MHz
(E9304A: 9kHz to 500MHz)
500 MHz to 1.2 GHz
1.2 GHz to 6 GHz ± 1.8 %
6 GHz to 14 GHz
14 GHz to 18 GHz
± 2.1 %
± 1.8 %
± 2.3 %
±1.9 %
± 3.3 %
± 2.1 %
± 4.0 %
Uncertainty (%)
(0 to 55 0C)
± 3.0 %
± 4.0 %
± 2.3 %
± 2.2 %
