Table 31. Rear panel information (continued)
Description Typical General characteristics
Bias tee input connector
Type BNC, female (for each port)
Maximum voltage ±35 VDC
Maximum current (no degradation in RF specifi cations) ±200 mA
Maximum current (damage level) ±500 mA
Fuse 500 mA, bi-pin style
Video output 15-pin mini D-Sub; female;
drives XGA compatible
monitors
GPIB 24-pin D-Sub (Type D-24),
female; compatible with
IEEE-488
USB-host port
Universal serial bus jack, Type A confi guration (4 contacts
inline, contact 1 on left); female; provides connection to
printer, ECal module, USB/GPIB interface or multiport test
set
Contact 1 Vcc: 4.75 to 5.25 VDC, 500
mA, maximum
Contact 2 – Data
Contact 3 + Data
Contact 4 Ground
USB (USBTMC 1 )
interface port
Universal serial bus jack,
Type B confi guration
(4 contacts inline); female;
provides connection to an
external PC; compatible
with USBTMC-USB488 and
USB 2.0.
LAN 10/100BaseT Ethernet, 8-pin
confi guration; auto selects
between the two data rates
Handler I/O port 36-pin centronics, female;
provides connection to
handler system
