8
Agilent 8510XF system performance
E7340A-005
(45 MHz to 85 GHz)
The following specifications describe the system performance of the 8510XF system in the E7340A-005
configuration, from 0.045 GHz to 85 GHz. The following system configuration was used to generate the specifi-
cations:
Test set: E7342A-005, millimeter controller and two test heads, 45 MHz to 85 GHz
RF sources: 83621B and 83651B synthesized sweepers (one each)
Calibration kit: 85059A 1.0 mm precision calibration/verification kit
Calibration techniques: SOLT to 50 GHz, and offset-shorts from 50 to 85 GHz
Dynamic range (for transmission measurements)
Frequency range (GHz)
0.045 - 2
2 - 18 18 - 40 40 - 50 50 - 65 65 - 75 75 - 85
Maximum power (in)
measured at port 2 0 dBm 0 dBm +10 dBm +10 dBm –3 dBm –3 dBm –3 dBm
Reference power (out)
at port 1 (nominal) 0 dBm 0 dBm –12 dBm –12 dBm –3 dBm –3 dBm –10 dBm
Minimum power (in)
measured at port 2 –74 dBm –104 dBm –84 dBm –84 dBm –80 dBm –80 dBm –70 dBm
Receiver dynamic range 74 dB 104 dB 94 dB 94 dB 77 dB 77 dB 67 dB
System dynamic range 74 dB 104 dB 72 dB 72 dB 77 dB 77 dB 60 dB
Measurement port characteristics
Frequency range (GHz)
RESIDUAL 0.045 - 2 2 - 18 18 - 40 40 - 50 50 - 65 65 - 75 75 - 85
Directivity 30 dB 30 dB 26 dB 24 dB 28 dB 28 dB 28 dB
Source match 27 dB 27 dB 23 dB 21 dB 28 dB 28 dB 28 dB
Load match 27 dB 27 dB 23 dB 21 dB 28 dB 28 dB 28 dB
Reflection tracking ±0.10 dB ±0.10 dB ±0.20 dB ±0.25 dB ±0.30 dB ±0.30 dB ±0.30 dB
Transmission tracking ±0.273 dB ±0.273 dB ±0.429 dB ±0.669 dB ±0.322 dB ±0.340 dB ±0.360 dB
Frequency range (GHz)
RAW (Typical) 0.045 - 2 2 - 18 18 - 40 40 - 50 50 - 65 65 - 75 75 - 85
Directivity 20 dB 20 dB 15 dB 15 dB 13 dB 10 dB 10 dB
Source match 20 dB 20 dB 15 dB 15 dB 13 dB 12 dB 12 dB
Load match 11 dB 11 dB 10 dB 10 dB 10 dB 10 dB 10 dB
