Symbol Definitions
] = CR/LF (carriage return/line feed, hex 0D 0A)
• = Space
X! = Shift control range (-63 to +63)
X@ = Controller firmware version (listed to two decimal places: x.xx)
X# = Frequency in Hz or kHz (listed as xxx.xx)
Command
ASCII (host to interface)
Response
(interface to host)
Additional
Description
Chn
]
Contact closure has been detected across pins 1 and 2.
NOTE:
Whenever the Input select button on the AAP device is pressed, contact closure is initiated at the
RGB 580xi remote interface and a signal is sent from the RS-232 port of the remote interface.
Horizontal shift
Specify horizontal shift
X!
H
Hph
X!]
Set horizontal shift value
Shift right one step
{H
Hph
X!]
Increment up
Shift left one step
}H
Hph
X!]
Increment down
Firmware version, part number, information requests, and reset
Query firmware version
number
Q/q
X@]
Display version (Ver. x.xx)
Request part number
7
N/n
N_60-362-01
]
Display part number of interface
Request information
I/i
Hph
X!•
Hrt
X@•
Vrt
X#]
Display status
RGB 580xi • Connection and Configuration
18
