RGB 460 Series • Reference Information 17
Accessories
Wall/Junction boxes Part number
JB 225 two-gang J-box, 2.5 inches deep 980084
JB 325 three-gang J-box, 2.5 inches deep 980083
JB 425 four-gang J-box, 2.5 inches deep 980097
Audio connector Part number
3.5 mm Mini Stereo-HQ/10 (quantity 10) 100-331-01
Cables
Male-to-male Molded VGA cables Part number
VGA M-M MD/6, 6 feet (1.8 m) 26-238-01
VGA-A M-M MD/3 (with audio), 3 feet (90 cm) 26-490-01
VGA-A M-M MD/6 (with audio), 6 feet (1.8m) 26-490-02
VGA-A M-M MD/12 (with audio), 12 foot (3.6 m) 26-490-03
BNC Series Mini High Resolution Cables
(non-plenum) Part number
MHR-5 BNC/3, 3 feet (90 cm) 26-260-15
MHR-5 BNC/6, 6 feet (1.8 m) 26-260-01
MHR-5 BNC/12, 12 feet (3.6 m) 26-260-02
MHR-5 BNC/25, 25 feet (7.6 m) 26-260-03
MHR-5 BNC/35, 35 feet (10.6 m) 26-260-17
MHR-5 BNC/50, 50 feet (15.2 m) 26-260-04
MHR-5 BNC/75, 75 feet (22.8 m) 26-260-16
MHR-5 BNC/100, 100 feet (30.4 m) 26-260-05
NOTE: A Setup Guide (part number 68-542-50) ships with all RGB 460xi Series interface
models. Depending on mounting, one of the following installation guides ship
with the interface:
Description Part Number
RGB 400xi Series MK Installation Guide 68-636-02
RGB 400xi Series Wall Box Installation Guide 68-636-03
RGB 460xi Steel City Box Installation Guide 68-636-04
RGB 460xi/472xi FSR Installation Guide 68-636-05
AKM UK Series Installation Guide 68-904-01
