RGB 460 Series • Reference Information 15
Enclosure type ................................ Metal
Enclosure dimensions
RGB 460xi faceplate ................ 4.5" H x 4.6" W x 0.1" D (2 gang)
(11.4 cm H x 11.7 cm W x 0.3 cm D)
RGB 460xi MK faceplate .......... 3.4" H x 5.7" W x 0.1" D
(8.6 cm H x 14.5 cm W x 0.3 cm D)
RGB 460xi FSR faceplate .......... 4.5" H x 3.5" W x 0.1" D
(11.4 cm H x 9.0 cm W x 0.3 cm D)
RGB 464xi/RGB 468Mxi faceplate
4.5" H x 6.4" W x 0.1" D (3 gang)
(11.4 cm H x 16.3 cm W x 0.3 cm D)
RGB 468xi faceplate ................ 4.5" H x 8.3" W x 0.1" D (4 gang)
(11.4 cm H x 21.2 cm W x 0.3 cm D)
RGB 468xi AKM faceplate ........ 3.0" H x 8.1" W x 0.6" D
(7.6 cm H x 20.6 cm W x 1.5 cm D)
RGB 460xi EC faceplates .......... 3.2" H x 4.4" W x 0.1" D
(8.0 cm H x 11.2 cm W x 0.3 cm D)
RGB 460xi SC-AFM2 faceplate . 2.9" H x 3.5" W x 0.1" D
(7.4 cm H x 8.9 cm W x 0.3 cm D)
RGB 464xi SC-AFM6 faceplate . 2.9" H x 8.9" W x 0.1" D
(7.4 cm H x 22.6 cm W x 0.3 cm D)
Interface enclosure for all models
2.7" H x 3.3" W x 1.0" D
(6.9 cm H x 8.4 cm W x 2.8 cm D)
(Depth excludes front panel connectors and controls.)
Enclosure dimensions
SC-AFM8 adapter plate ........... 4.4" x H x 9.4" W x 0.1" D
(11.2 cm H x 23.9 cm W x 0.3 cm D)
Product weight
RGB 460xi SC-AFM2, RGB 460xi FSR
0.5 lbs (0.3 kg)
RGB 464xi SC-AFM6 ................ 0.8 lbs (0.4 kg)
SC-AFM8 ................................. 0.6 lbs (0.3 kg)
RGB 460xi ............................... 0.5 lbs (0.2 kg)
RGB 460xi MK ......................... 0.5 lbs (0.2 kg)
RGB 464xi, RGB 468xi, RGB 468 Mxi
0.7 lbs (0.3 kg)
EC models ............................... 0.7 lbs (0.3 kg)
RGB 468xi AKM ....................... 0.8 lbs (0.4 kg)
Shipping weight
RGB 468xi AKM ....................... 2 lbs (1 kg)
All other models ...................... 3 lbs (2 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
