RGB 460 Series • Reference Information 14
Audio — all models
Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB
Response ........................................ 20 Hz to 20 kHz, ±0.5 dB
THD + Noise ................................... 0.03% @1 kHz, 0.3% @ 20 kHz at nominal level
S/N ................................................. >90 dB at maximum output (14 dBu), balanced (unweighted)
Stereo channel separation .............. >90 dB @ 1 kHz to 20 kHz
Audio input — RGB 464xi
Number/signal type ........................ 2 stereo, unbalanced, 20 Hz to 20 kHz
Connectors .................................... Ch. 1: 3.5 mm female stereo jack (2 channel), unbalanced; tip (L), ring (R),
sleeve (ground)
Ch. 2: 2 RCA female jacks
Impedance ..................................... >5k ohms unbalanced, DC coupled
Nominal level ................................. -10 dBV (316 mV)
Maximum level ............................... +8.5 dBu (unbalanced) at 1% THD+N
Audio input — RGB 460xi, RGB 460xi EC, RGB 460xi FSR, RGB 468Mxi, RGB 468xi,
RGB 468xi AKM
Number/signal type ........................ 1 stereo, unbalanced, 20 Hz to 20 kHz
Connectors .................................... 3.5 mm female stereo jack (2 channel), unbalanced; tip (L), ring (R),
sleeve (ground)
Impedance ..................................... >5k ohms unbalanced, DC coupled
Nominal level ................................. -10 dBV (316 mV)
Maximum level ............................... +8.5 dBu (unbalanced) at 1% THD+N
Audio output— RGB 464xi
Number/signal type ........................ 2 buffered, stereo (2 channel), balanced/unbalanced
Connectors .................................... (2) 3.5 mm captive screw connectors, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±0.1 dB channel to channel
Maximum level (600 ohm) .............. +14 dBm, balanced at 1% THD+N
Audio output — RGB 460xi, RGB 460xi EC, RGB 460xi FSR, RGB 468Mxi, RGB 468xi,
RGB 468xi AKM
Number/signal type ........................ 1 buffered, stereo (2 channel), balanced/unbalanced
Connectors .................................... 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 50 ohms unbalanced,100 ohms balanced
Gain error ...................................... ±0.1 dB channel to channel
Maximum level (600 ohm) .............. +14 dBm, balanced at 1% THD+N
NOTE: 0 dBu = 0.775 V, 0 dBV = 1 V, 0 dBV ≈ 2 dBu.
General
Power ............................................ Supplied by an included 12 VDC, 1 A external power supply
External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external; to 9 to 12 VDC, 0.2 A, regulated
Power input requirements .............. 12 VDC, 0.2 A (minimum)
Temperature/humidity .................... Storage: -40 to 158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32° to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Mounting
Floor box mount
RGB 460/464/468xi SC models
Steel City AFM floor box mountable
RGB 460xi MK ................... MK box mountable
RGB 468xi AKM ................. Ackerman UK floor box mountable
All other models ...................... Wall or furniture mountable
