RGB 460 Series • Reference Information 13
Reference
Information
The following reference section contains product specifications, replacement parts numbers
and AAP and MAAP architectural plate order details.
• Specifications
• Ordering Information
• Mounting Adapter Plates (AAPs or MAAPs)
Specifications
Video
Gain ............................................... Unity (0.7 V), 15% with 3 dB peaking (0.8 V), 30% with 6 dB peaking (0.9 V)
Bandwidth ..................................... 300 MHz (-3 dB)
Video input and loop through
Number/signal type ........................ 1 analog RGBHV, RGBS, RGsB
Connectors .................................... 1 female 15-pin HD buffered input connector
1 female 15-pin HD local monitor loop through connector
Nominal level ................................. 0.7 Vp-p for RGB
Minimum/maximum levels .............. Analog: 0.3 V to 1.45 Vp-p with no offset at unity gain
Impedance ..................................... 75 ohms or Hi Z, switchable (set to 75 ohms if no local monitor is connected)
Horizontal frequency ...................... 15 kHz to 150 kHz (optimum: 15 kHz to 62 kHz)
Vertical frequency ........................... 30 Hz to 170 Hz
Return loss ..................................... <-30 dB @ 5 MHz
Video output
Number/signal type ........................ 1 analog RGBHV, RGBS, RGsB
Connectors .................................... 5 female BNC on 2" to 2.5" cables
Nominal level ................................. 0.7 Vp-p for RGB
Minimum/maximum levels .............. Analog: 0.7 V to 0.9 Vp-p (switch selectable) with peaking and 0.7 Vp-p input
Impedance ..................................... 75 ohms
Return loss ..................................... -30 dB @ 5 MHz
Sync
Input type ...................................... Autodetect RGBHV, RGBS, RGsB (accepts RGsB but does not strip from video)
Output type ................................... RGBHV: at all times
RGBS: switch selectable
RGsB: switch selectable or pass-through
Input level ...................................... 2.0 V to 5.5 Vp-p with +0.2 VDC offset max.
Output level ................................... 4.0 V to 5.0 Vp-p, unterminated
Input impedance ............................ 510 ohms
Output impedance ......................... 75 ohms
Max. propagation delay .................. 52 ns
Max. rise/fall time ........................... 2.5 ns
Polarity ........................................... Positive or negative
