26 SMX System MultiMatrix Switcher • SIS Programming Guide
Command
ASCII Command (host to switcher)
Response (switcher to host)
Additional Description
Information Requests
NOTE:
Firmware version, part number
, and information are for the primary frame only
.
Query firmware version
Q
X2!]
Example:
Q
1.14
]
Ver01*
X2!
]
V
erbose mode 2 or 3
Query system status
S
X2$
•
X2$
•
X2$
•
X2%
•
X2^
•
X7&
•
X7*]
Example:
S
Sts0*3.31 4.98 24.22 +100.40 03305 03308 1 0
]
(V
erbose mode 2 or 3)
3.31
and
4.98
are power supply voltages;
24.22
is fan voltage,
100.40
(degrees F) is temperature,
03305
is fan 1 rpm,
03308
is fan 2
rpm,
1 is primary power supply (OK).
Query Switcher Information per plane (16 actual and 10 virtual) plus board configuration
I
V
X@
0
X
X#
0
A
X@
0
X
X#
0
•...
V
X@
15
X
X#
15
A
X@
15
X
X#
15
•...
V
X@
25
X
X#
25
A
X@
25
X
X#
25
]
V16x16A16x16
•
V--
X--
A--
X--
•
V--
X--
A--
X--
•
V--
X--
A--
X--
•
...
V--
X--
A--
X--
]
NOTE:
The
I response gives 26 parameters, the first 16 (V_x_A_x_) are plane information (planes 0-15), and the next are
virtual planes 1 - 10 (
90
-
99
).
Query plane address per slot
E
STAT
}
X2@
(slot 1)
•
X2@
(slot 2)
•...
X2@
(slot 6/8/10)
]
Stat
X2@
(slot 1)
•
X2@
(slot 2)
•...
X2@
(slot 6/8/10)
]
Slot 1
2
3
4
5
6
7
8
9
10
Example:
Stat* 00
•
01
•
--
•
02
•
--
•
--
•
03
•
--
•
03
•
03
]
(5U frame, 10 slots)
--
indicates no boar
d is installed
NOTES:
X@
= Input number
01
- <
maximum num
ber of inputs
>,
00
= untied
X#
= Output number
01
- <
maximum number of
outputs
>
X2!
= Firmware version number
x.xx
X2@
= Plane number
X2^
= Fan speed (rpm)
X2$
= V
oltage (
+ or
- voltage)
X7&
= Primary power supply
0 = not installed,
1 = OK
X2%
= T
emperature
X7*
= Secondary (redundant) power supply
0 = not installed,
1 = OK
