Input Audio Level Table
dB Color
Output Buttons Lit
or Flashing
+/-
dB
Color Output Buttons Lit
or Flashing
+/-
24
green
12
>
-01
red
1 flash
<
23
green
12 flash
>
-02
red
1 flash
<
22
green
11
>
-03
red
2 flash
<
21
green
11 flash
>
-04
red
2 flash
<
20
green
10
>
-05
red
3 flash
<
19
green
10 flash
>
-06
red
3 flash
<
18
green
9
>
-07
red
4 flash
<
17
green
9 flash
>
-08
red
4 flash
<
16
green
8
>
-09
red
5 flash
<
15
green
8 flash
>
-10
red
5 flash
<
14
green
7
>
-11
red
6 flash
<
13
green
7 flash
>
-12
red
6 flash
<
12
green
6
>
-13
red
7 flash
<
11
green
6 flash
>
-14
red
7 flash
<
10
green
5
>
-15
red
8 flash
<
09
green
5 flash
>
-16
red
8 flash
<
08
green
4
>
-17
red
9 flash
<
07
green
4 flash
>
-18
red
9
<
06
green
3
>
>
= Esc
<
= View
05
green
3 flash
>
04
green
2
>
03
green
2 flash
>
02
green
1
>
01
green
1 flash
>
00
Not lit
NOTES:
•
There is only one audio level setting per input and
one per output on an audio plane. The audio level
and volume is shared by the left and right inputs and
outputs.
•
Audio levels and volumes are stored in nonvolatile
memory. When power is removed or restored, settings
are retained.
