1-3 PVS 305SA Switcher • Introduction
Features
Twisted pair inputs — The PoleVault switcher accepts two independent, high
resolution RGB video and audio signals, and two configurable inputs for either
composite video or high resolution RGB signals, and audio signals, transmitted
on twisted pair cable from a source up to 100 ft away.
Video output — The PoleVault switcher can switch between four inputs (either
four RGB or two RGB and two composite).
VoiceLift input — The PoleVault switcher can mix a mono line level audio input
from the VoiceLift microphone system with the audio input from the video/
audio source.
Amplified Audio output — The PoleVault switcher allows user selectable stereo or
dual mono, 2/4/8 ohm audio outputs through the integrated audio amplifier.
Line Out output — The PoleVault switcher allows for the connection of a recording
or listening device for audio output.
Paging System support — The PoleVault switcher allows for the connecting of a
public address paging system sensor which when activated, mutes the PoleVault
switcher’s program for the duration of the PA broadcast.
Executive Mode — To prevent unauthorized access the PoleVault switcher panel
can be locked (executive mode) via the front panel or RS-232. An LED on the
front panel indicates executive mode status.
Control and configuration — Firmware updates to the PVS 305SA can be made via
a front panel config port. The PoleVault switcher can also be configured via
RS-232 and controlled via the front panel, RS-232, or wired IR.
Other features include:
• User selectable switching of input and status indication LED
• Rear panel mounted captive screw connector for RS-232, MLC, or IR control
• Rear panel mounted captive screw connector for external volume control
• Energy efficient design offers Extron exclusive Auto Power Save and Standby
modes designed to lower energy usage and reduce costs.
