13 – IRIS 150 V1.11 User Guide
iQuest (NZ) Ltd - PO Box 15169, Hamilton, New Zealand Tel: +64 7 857-0810 Fax: +64 7 857-0811 Email: [email protected] 13
Option 2
Select this option to change the scan mode and rate for the unit. The scan rate represents the number of
minutes that should elapse between successive scans when the mode is “Timed”. See Section 6.3 for
further information on scan modes and scan rates.
Option 3
Select this option to display the Sensor Cfg sub-menu. This sub-menu is for configuring the individual
sensors.
Option 4
Select this option to display the Totaliser sub-menu. This allows the running total of the two totalisers to
viewed and adjusted if desired to match for example, a water meter.
Option 5
Select this option to display the Digital Output Cfg sub-menu. This is for configuring the digital output.
Option 6
Select this option to display the Date/Time sub-menu. This is for configuring the real time clock.
Option 7
When this option is selected you will be prompted to enter a security PIN code between 0 and 9999. This
PIN code is used to restrict access to specific LCD screens. If the PIN code is set to 0 (factory default) then
only the four status and the totaliser (view only) LCD screens are accessible.
> PIN Code=
Option 8 - Miscellaneous
Select this option to display the Miscellaneous configuration menu.
5.3.2 Sensor Selection (Level 2)
The Sensor Configuration menu is where you select the sensor that you want to configure. From this menu,
you can see at a glance which sensors are enabled for logging and if enabled, their source and name.
* Sensor Cfg
0 Exit
1 Sen1 [Dis]
2 Sen2 [Dis]
3 Sen3 [Dis]
4 Sen4 [Dis]
>
Option 0
Select this option to return to the main menu.
Option 1
Select this option to display the set-up menu for Sensor 1.
Option 2
Select this option to display the set-up menu for Sensor 2.
Option 3
Select this option to display the set-up menu for Sensor 3.
Option 4
Select this option to display the set-up menu for Sensor 4.
