5.3 Terminal Menus
When a terminal session has been established with the iRIS through the RS232 port you will be presented
with a welcome message and the main menu will be displayed. To make a menu selection, type a number
followed by . Invalid menu selections will result in the display of an error message on the terminal.
The current value of each settable item is enclosed in square braces (e.g. [1234]). To keep the current value
for any setting, just press when prompted for a new value.
The terminal menu structure is shown graphically below:
Level 1
Level 2
Level 3
Level 4
Level 5
Figure 5 – Terminal Menu Structure
5.3.1 Main Menu (Level 1)
The first menu displayed is the Main Menu. This menu is the only level 1 menu. There are nine options
available, three of which are lower level sub-menus:
* iRIS 150 (SN AG3-0000 / F1.11 / S1.11)
1 Site Name [My Site Name]
2 Scan Mode [Continuous]
3 Sensors
4 Totals
5 Output
6 Date/Time [17 Jul 2008, 08:36:50, UTC +12]
7 PIN Code [0001]
8 Miscellaneous
>
Option 1
Select this option to enter a name for the site that will be displayed on the main title screen of the LCD. Note
that the maximum length of the site name is fixed at 19 characters.
Main
Menu
Sensor
Selection
Output
Configuration
Sensor
Configuration
Alarm
Configuration
Alarm
Selection
Totaliser View
/ Synchronise
Date/Time
Configuration
Miscellaneous
Configuration
