6 outputs, 1 outputs of the iq sensor net, Outputs -1 – YSI IQ S ENSOR N ET System 182 User Manual
Page 91: Outputs of the iq s, Chapter 6 o, Utputs, 6outputs

System 182
Outputs
6 - 1
ba76022e01
12/2011
6
Outputs
6.1
Outputs of the IQ S
ENSOR
N
ET
The IQ S
ENSOR
N
ET
Universal Transmitter has three relays outputs
and two current outputs.
Functions for relay
outputs
System monitoring
Sensor monitoring
Limit indicator
Frequency controller
Pulse-width output
Sensor controlled
Cleaning
Manual control
Relay outputs can be configured as opener or closer.
Functions for current
outputs
Recorder
PID controller
Fixed current value
Note
You can view the current states of the relay and current outputs in the
measured value and status display (see section 4.2).
Valve outputs
(MIQ/CHV PLUS)
The MIQ/CHV PLUS valve module is administrated by the system as a
valve output (designation, MIQ/CHV PLUS V1). The relevant setting
tables are available via the SETTINGS menu.
Note
The installation and settings of the valve module are described in the
operating manual of the MIQ/CHV PLUS.
