Logging Section 9
YSI Incorporated YSI 556 MPS Page 69
Multi-site Description are characterized by a file name, but not a site name,
since multiple sites are involved. However, each data point has a Site
Number attached to it so that the user can easily determine the sampling site
when viewing the data from the YSI 556 MPS File menu or processing the
data in EcoWatch for Windows after upload to a PC.
Site List
Single-Site Descriptions
with Different File
Names
Figure 9.4 Single-Site Descriptions
Site List
Multi-Site
Descriptions
with the Same
File Name
Figure 9.5 Multiple-Site Descriptions
NOTE: Site lists containing Single Site Descriptions are usually input with
the designation Store Site Number INACTIVE in the YSI 556 MPS
Logging setup menu. Thus, no site numbers appear in the first Site list
example. Conversely, Site lists containing Multi-Site Descriptions MUST
be input with the Store Site Number selection ACTIVE as shown in the
second example.
