File Section 8
YSI Incorporated YSI 556 MPS Page 59
8.4 Upload to PC
EcoWatch™ for Windows™ must be used as the PC software interface to
the YSI 556 MPS. Refer to Appendix G EcoWatch for more information.
EcoWatch for Windows
® is available at no cost via a download from the
YSI Web Site (www.ysi.com) or by contacting YSI Customer Support.
Refer to Appendix E Customer Service.
8.4.1 Upload Setup
1. Disconnect the YSI 5563 Probe Module from the YSI 556
MPS instrument.
2. Connect the YSI 556 MPS to a serial (Comm) port of your
computer via the 655173 PC Interface cable as shown in the
following diagram:
556 MPS
Computer with
EcoWatch for
Windows
Installed
655173 PC
Interface Cable
DE-9 PC Serial Port
Figure 8.2 Computer/Instrument Interface
3. Open EcoWatch for Windows on your computer.
NOTE: See Appendix G EcoWatch for installation
instructions.
4. Click on the sonde/probe icon in the upper toolbar.
