17 P1 DIMM1B,
P1 DIMM1A,
P1 DIMM2B,
P1 DIMM2A,
P1 DIMM3B,
P1 DIMM3A, DDR3 sockets for processor 1
18 JWR 12 V 20-pin power connectors
19 JF2 Proprietary slot for power, FP control and
I-SATA connections
20 CPU2 Processor 2 socket
21 Slot 1 PCI expansion slot
22 JNMI1 NMI (Non-Masked Interrupt) header
23 JWD1 Watch Dog Enable/Disable/Reset
No. Connector Description
