ZXBM1021
Application Information
(cont.)
Part Number Type
B
VDSS
(V)
I
D
(A)
R
DS(ON)
@ V
GS
= 10V
( Ω)
Package
Power Switch: P-Channel MOSFETS
ZXMP10A18K P -100 -5.9 0.150 TO252
ZXMP10A18G P -100 -3.7 0.150 SOT223
ZXMP10A17E6 P -100 -1.6 0.350 SOT26
ZXPM6A17DN8 2 x P -60 -3.2 0.125 SO8
ZXMP6A18K P -60 -10.4 0.055 TO252
DMP4025LSD 2 x P -40 -7.6 0.025 SO8
DMP4015SPS P -40 -13 0.011 POWERDI5060-8
ZXMP4A16G P -40 -6.4 0.060 SOT223
DMP3008SFG P -30 -11.7 0.017 POWERDI3333-8
BJTs
Part Number Type
V
CEO
( V )
I
C
( A )
V
CE(sat)
@I
C
/I
B
( mV@A/mA )
Package
Power switch: NPN BJT
FZT855 NPN 150 4 65 @ 0.5/50 SOT223
FMMT624 NPN 125 1 150 @ 0.5/50 SOT23
ZX5T853G NPN 100 6 125 @ 2/100 SOT223
ZXTN19100CZ NPN 100 5.25 65 @ 1/100 SOT89
ZXTN25100BFH NPN 100 3 135 @ 0.5/10 SOT23
ZXTN25100DFH NPN 100 2.5 170 @ 0.5/10 SOT23
FCX493 NPN 100 1 300 @ 0.5/50 SOT89
FCX1053A NPN 75 3 200 @ 1/10 SOT89
ZXTN19060CG NPN 60 7 155 @ 1/10 SOT223
ZX5T851G NPN 60 6 135 @ 2/50 SOT223
DXT2010P5 NPN 60 5 70 @ 1/10 PowerDI5
FCX493A NPN 60 1 500 @ 1/50 SOT89
FCX619 NPN 50 3 260 @ 2/50 SOT89
FMMT619 NPN 50 2 220 @ 2/50 SOT23
FCX619 NPN 50 3 260 @ 2/50 SOT89
Drive Buffer and Level Shift
FMMT493 NPN 100 1 300 @ 0.5/50 SOT89
FMMT493A NPN 60 1 250 @ 0.5/50 SOT23
ZXTN2038F NPN 60 1 250 @ 0.5/50 SOT23
DSS41604 NPN 60 1 140 @ 0.5/50 SOT563
