ZXBM1021
Application Information
(cont.)
External Drive Transistors
Diodes offers a range of devices that are ideally suited to interface between the ZXBM1021 pre-driver and the motor. The following tables show a
selection of products. For more comprehensive listings or the latest information please refer to the Diodes website:
MOSFETs
Part Number
Type
BV
DSS
(V)
I
D
(A)
R
DS(ON)
@ V
GS
= 10V
(4.5V for 20V parts) (
Ω)
Package
Power Switch: N-Channel MOSFETs
DMC2020USD
N
P
20
-20
7.4
-5.9
0.020
0.033
SO8
DMC2038LVT
N
P
20
-20
4.5
-3.2
0.035
0.074
TSOT26
DMC3028LSD
N
P
30
-30
7.1
-7.4
0.028
0.025
SO8
DMC4040SSD
N
P
40
-40
7.5
-7.3
0.025
0.025
SO8
DMC4028SSD
N
P
40
-40
7.2
-5.2
0.028
0.050
SO8
ZXMC4559DN8
N
P
60
-60
4.7
-3.9
0.055
0.085
SO8
ZXMC6A09DN8
N
P
60
-60
5.1
-4.8
0.045
0.055
SO8
Part Number
Type
BV
DSS
(V)
I
D
(A)
R
DS(ON)
@ V
GS
= 10V
(
Ω)
Package
Power Switch: N-Channel MOSFETs
ZXMN10A09K
N
100
7.7
0.085
TO252-3L
ZXMN10A25K
N
100
4.0
0.125
TO252-3L
ZXMN10A11G
N
100
2.4
0.35
SOT223
ZXMN10A08DN8
2 x N
100
2.1
0.25
SO8
ZXMN10B08E6
N
100
1.9
0.230
SOT23-6
ZXMN10A07Z
N
100
1.4
0.7
SOT89
ZXMN6A09K
N
60
11.2
0.04
TO252-3L
ZXMN6A25K
N
60
10.7
0.05
TO252-3L
DMN6068LK3
N
60
8.5
0.068
TO252-3L
ZXMN6A09G
N
60
7.5
0.04
SOT223
ZXMN6A25G
N
60
6.7
0.05
SOT223
ZXMN7A11K
N
60
6.1
0.120
TO252-3L
ZXMN6A09DN8
2 x N
60
5.6
0.04
SO8
DMN6068SE
N
60
5.6
0.068
SOT223
ZXMN6A08G
N
60
5.3
0.08
SOT223
ZXMN6A25DN8
2 x N
60
4.7
0.055
SO8
ZXMN6A11Z
N
60
3.6
0.120
SOT89
ZXMN6A07Z
N
60
2.2
0.250
SOT89
ZXMN6A07F
N
60
1.4
0.250
SOT23
