ZXBM1021
Application Information
(cont.)
S
MIN
Minimum Speed Setting
Minimum speed setting prevents the motor from running below a set speed regardless of whether the control applied is for a slower speed (either
DC or PWM input). The minimum motor speed is chosen based on a speed below which the motor may or fail to start.
The S
MIN
pin voltage sets a maximum voltage clamp for the SPD pin.
For a DC voltage input into SPD pin, the voltage range 3V to 1V represents 0% to 100% of full speed. In order to set a minimum speed of 20%,
S
MIN
should be set 20% into this range below 3V, i.e 2.6V.
Minimum speed is set by the voltage on the S
MIN
pin, using a potential divider from the ThRef voltage output as shown below.
The S
MIN
voltage is given by
MI
Th ef
10
9 10
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
1
1.2
1.4
1.6
1.8
2
2.2
2.4
2.6
2.8
3
M
o
to
r
spe
e
d
(%
)
DC speed control voltage at SPD pin (V)
SPD and SMIN Voltages vs Motor Speed
