2.4 Hard disk drives
To install a hard disk drive:
1. Open the front bezel to access
the hot-swap drive trays.
2. Release a drive tray by pushing
the spring lock to the right, then
pulling the tray lever outward.
The drive tray ejects slightly
after you pull out the lever.
3. Firmly hold the tray lever and
pull the drive tray out of the
bay.
4. An empty drive tray includes a
metal bracket for support. Use a
Phillips (cross) screwdriver to
remove the bracket if you wish
to install a hard disk in the drive
tray.
Metal bracket
