5.4.6 5.4.6 5.4.6 5.4.6 5.4.6 Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration
Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3] Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Configuration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to set the BIOS selection mode for Serial Port2.
Configuration options: [Normal] [IrDA] [ASK IR]
Parallel Port Address [Disabled] Parallel Port Address [Disabled] Parallel Port Address [Disabled] Parallel Port Address [Disabled] Parallel Port Address [Disabled]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [IRQ7]
Allows you to select the Parallel Port IRQ.
[Configuration options: [IRQ5] [IRQ7]
Configure Win627EHF Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port Address [Disabled]
Allows BIOS to Select
Serial Port1 Base
Addresses.
This item appears only in NCL-DS1 and NCL-D1 models.
