1.2 System specifications
The ASUS AP2400R-E2 is a 2U barebone server system featuring the ASUS
NCL-DS1R2 motherboard. The server supports dual Intel® Xeon™
processors with EM64T technology, plus other latest technologies through
the chipsets onboard.
C h a s s i s C h a s s i s C h a s s i s C h a s s i s C h a s s i s
M o t h e r b o a r d M o t h e r b o a r d M o t h e r b o a r d M o t h e r b o a r d M o t h e r b o a r d
C h i p s e t C h i p s e t C h i p s e t C h i p s e t C h i p s e t
C P U C P U C P U C P U C P U
M e m o r y M e m o r y M e m o r y M e m o r y M e m o r y
L A N L A N L A N L A N L A N
V G A V G A V G A V G A V G A
S C S I S C S I S C S I S C S I S C S I
E x p a n s i o n E x p a n s i o n E x p a n s i o n E x p a n s i o n E x p a n s i o n
s l o t s
s l o t s s l o t s s l o t s s l o t s
S t o r a g e S t o r a g e S t o r a g e S t o r a g e S t o r a g e
F r o n t p a n e l F r o n t p a n e l F r o n t p a n e l F r o n t p a n e l F r o n t p a n e l
R e a r p a n e l R e a r p a n e l R e a r p a n e l R e a r p a n e l R e a r p a n e l
Rackmount 2U (AR21)
ASUS NCL-DS1R2
North Bridge: Intel ® E7520 MCH
South Bridge: Intel ® 82801ER
I/O Bridge: Intel ® 6700PXH Bridge
Supports dual Intel ® Xeon™ 3.6 GHz processors with L2
1 MB and 2 MB caches via two 604-pin sockets
8 x 184-pin DDR sockets for up to 16 GB system memory
Supports PC2700 registered ECC DDR DIMMs
2 x Broadcom® BCM5721 PCI Express Gigabit LAN
controllers
ATI RAGE-XL PCI-based VGA controller
Supports 8MB display memory
Adaptec ® AIC-7902W Ultra320 Dual-channel SCSI controller
3 x full-length 64-bit/66MHz 3V PCI-X slots (on a riser card)
1 x low-profile 64-bit/133MHz 3V PCI-X slot
8 x 3.5-inch hot-swappable HDD bays
1 x slim optical drive
1 x slim 1.44MB floppy drive
2 x USB 2.0 ports
Power switch
Reset switch
Location switch
Power, HDD access, location, message, LAN
HDD LEDs: Status, activity
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x Serial port
1 x VGA port
2 x USB 2.0 ports
2 x RJ-45 ports (with LEDs)
1 x external SCSI port (alternative)
(continued on the next page)
