GE Drive Systems
SUPPLEMENT
FOR INSTRUCTION MANUAL GEK-85716A
These instructions do not purport to cover all details or variations in equipment, nor to provide for possible contingency to be met
during installation, operation, and maintenance. Should further information be desired or should particularproblems that are not
covered for the purchaser’s purpose, matter should be referred to GE Drive Systems, Salem, Virginia U.S.A.
This supplement contains additional information
needed when installing and operating the
series of inverters. Refer to the information of this
supplement in addition to that contained in
85716A for the figures, tables, and paragraphs listed in
this supplement.
Figure Basic Connection Diagram
Figure S-12. Control Block Diagram
The AC circuit breaker shown in these figures
is incorrectly illustrated as three breakers. It is actually
a single, breaker.
Table Function Code Data
Table 6: Function Code Descriptions
Function Code lb, Electronic Thermal Overload
Protection, that is built in to the AF-300C series of
inverters is factory set as Operational. If the user
changes this to Non-Operational, conventional
overload protection for the motor and wiring must
then be provided by the user. Typical wiring for an
overload relay is shown in figure 8-12 of GEK-85716A.
All inverter installations meet the applicable na-
tional (NEC, CEC) and local electrical codes. It is the
system engineer’s responsibility to be certain that the
inverter installation complies with all applicable
electrical codes. (If a system engineer is not involved,
it is the user’s responsibility.)
Page 1 of 1
