Modifications reserved Page 23/83
OPM_SGS_USM_10K_40K_0US_V030.doc Operating Manual SG Series 10 –20 – 30 - 40 kVA
6.1 METERING MODE
The metering mode is entered any time the metering button is pressed.
While in this mode the LCD will display a series of screens containing metering information.
In this mode the buttons perform the following functions:
metering
Scrolls forward to the next screen.
alarms Abandons the metering mode and enters the alarms mode.
parameters Abandons the metering mode and enters the parameters mode.
+ Scrolls forward to the next screen.
– Scrolls backward to the previous screen.
ok Displays the main screen for this mode.
Main screen
This screen displays the current status of the UPS in a condensed form.
The information offered by this screen consists of:
• The type of the machine: Family name, series number (P + unit number for parallel version from 1
to 8) and power range.
• The status of the load.
• The Load amount as a percentage of the nominal Load (referred to the most loaded phase).
• The estimated Battery backup time in minutes with the present load.
SG Series S0 30kVA
LOAD ON INVERTER
LOAD = 84%
Autonomie = 12min
metering
alarms
parameters
+
–
ok
Battery data screen
This screen displays:
• The Battery voltage.
• The Battery Current (negative values correspond to the discharge of the Battery).
• The temperature of the Battery (XXX indicates sensor disabled).
• The current charge level.
• The estimated backup time with the present load.
Ub=540V Ib= + 15A
Battery Temp= + 20°C
Charge Level= 87%
Autonomy = 12min
metering
alarms
parameters
+
–
ok
Bypass Utility data screen
This screen refers to the AC source supplying the Bypass. This screen displays:
• The frequency.
• The voltage levels of the three phase voltages.
U T IL IT Y
f = 6 0 .0 H z
U 1 = 2 7 6 V U 2 = 2 7 5 V
U 3 = 2 7 7 V
m e te rin g
a la rm s
p a ra m e te rs
+
–
o k
