Lineage Power 3
Data Sheet
June 26, 2009
36-75 Vdc Input; 1.2 Vdc to 5 Vdc Output; 6.6A to 12A
HW006/010/012 Series Power Modules; dc-dc Converters
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Output Voltage Set Point
(VI = 48 Vdc; IO = IO, min to IO, max, TA = 25 °C) HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
Vo, set
Vo, set
Vo, set
Vo, set
Vo, set
Vo, set 1.17
1.46
1.75
2.46
3.25
4.92 1.2
1.5
1.8
2.5
3.3
5.0 1.23
1.54
1.85
2.54
3.35
5.08 Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Output Voltage
(Over all operating input voltage, resistive load, and
temperature conditions at steady state until end of life.) HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
VO
VO
VO
VO
VO
VO 1.15
1.44
1.73
2.42
3.2
4.85
—
—
—
—
—
— 1.25
1.56
1.87
2.57
3.4
5.15
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Output Regulation:
Line (VI = VI, min to VI, max)
Load (IO = IO, min to IO, max)
Temperature (TA = TA, min to TA, max) All
All
All —
—
— —
—
— —
—
0.2
0.1
10
—
%, VO, set
mV
%, VO, set
Output Ripple and Noise
Measured across 10µF Tantalum, 1µF
Ceramic, VI = VI, nom TA = 25 °C, IO = IO, max See test
Configuration section
RMS (5 Hz to 20 MHz bandwidth)
Peak-to-peak (5 Hz to 20 MHz bandwidth) All
All —
— 8
40
20
75 mVrms
mVp-p
External Load Capacitance HW006A6A1
All others
CO, max
CO, max 0
0 —
— 470
1000
µF
µF
Output Current
(At Io < Io,min, the output ripple may exceed the
maximum specifications. All modules shall operate at no
load without damage and without exceeding 110% of VO,
set.) HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
IO
IO
IO
IO
IO
IO 0.15
0.15
0.15
0.05
0.05
0.05 —
—
—
—
—
— 12
12
12
10
10
6.6
Adc
Adc
Adc
Adc
Adc
Adc
Output Current-limit Inception
(VO = 90% of VO, set) HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
IO, lim
IO, lim
IO, lim
IO, lim
IO, lim
IO, lim —
—
—
—
—
— 18
18
18
12
12
8
—
—
—
—
—
— Adc
Adc
Adc
Adc
Adc
Adc
Output Short-circuit Current (Average)
VO = 0.25 V HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
IO, s/c
IO, s/c
IO, s/c
IO, s/c
IO, s/c
IO, s/c —
—
—
—
—
— 20
20
20
17
17
13 —
—
—
—
—
— Adc
Adc
Adc
Adc
Adc
Adc
Efficiency
(VI = VIN, nom; IO = IO, max), TA = 25 °C HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
h
h
h
h
h
h —
—
—
—
—
— 82
83
85
89
90
91 —
—
—
—
—
— %
%
%
%
%
%
Switching Frequency All fSW — 285 — kHz
Efficiency
(VI = VIN, nom; IO = IO, max), TA = 25 °C HW012A0P1
HW012A0M1
HW012A0Y1
HW010A0G1
HW010A0F1
HW006A6A1
h
h
h
h
h
h —
—
—
—
—
— 82
83
85
89
90
91 —
—
—
—
—
— %
%
%
%
%
%
