GE Industrial Solutions HW006-010-012 Series - Manual (Page 23)

Document No: ADS02-006EPS ver.1.4
PDF Name: fds03-0031.pdf
Data Sheet
June 26, 2009
36-75 Vdc Input; 1.2 Vdc to 5 Vdc Output; 6.6A to 12A
HW006/010/012 Series Power Modules; dc-dc Converters
World W ide Headq u ar ter s
Lin eag e Po wer Co rp oratio n
30 00 Sk yline D riv e, Mes quite, T X 75149, U SA
+1-800-526-7819
(Outs id e U .S.A .: +1- 97 2-2 84 -2626)
www.line ag ep ower .co m
e-m ail: tech sup por t1@ lin ea gep ower .co m
A sia-Pacific Head qu art er s
T el: +65 6 41 6 4283
Eu ro pe, M id dle-East an d Afr ic a He ad qu ar ter s
T el: +49 8 9 6089 286
Ind ia Head qu arter s
T el: +91 8 0 28411633
Lineage Power reserves the right to m ake changes to the produc t(s) or inform ation contained herein without notice. No liability is ass um ed as a res ult of their use or
applic ation. No rights under any patent acc ompany the sale of any s uc h pr oduct(s ) or information.
© 2008 Lineage Power Corpor ation, (M esquite, Texas ) All International Rights Res er ved.
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Optional features can be ordered using the suffixes shown below. The suffixes follow the last letter of the Product Code and are
placed in descending alphanumerical order.
Table 2. Device Options
Input Voltage
Output
Voltage
Output
Current
Efficiency Connector Type Device Code Comcodes
36 – 75 Vdc 1.2 V 12 A 82 Through-Hole HW012A0P1 108965591
36 – 75 Vdc 1.5 V 12 A 83 Through-Hole HW012A0M1 108968389
36 – 75 Vdc 1.8 V 12 A 85 Through-Hole HW012A0Y1 108968405
36 – 75 Vdc 2.5 V 10 A 89 Through-Hole HW010A0G1 108968421
36 – 75 Vdc 3.3 V 10 A 90 Through-Hole HW010A0F1 108965625
36 – 75 Vdc 3.3 V 10 A 90 Through-Hole HW010A0F1Z CC109107141
36 – 75 Vdc 5.0 V 6 A 91 Through-Hole HW006A6A1 108968363
36 – 75 Vdc 5.0 V 6 A 91 Through-Hole HW006A6A1Z CC109107133
36 – 75 Vdc 1.2 V 12 A 82 SMT HW012A0P1-S 108965617
36 – 75 Vdc 1.2 V 12 A 82 SMT HW012A0P1-SZ 109100360
36 – 75 Vdc 1.5 V 12 A 83 SMT HW012A0M1-S 108968371
36 – 75 Vdc 1.5 V 12 A 83 SMT HW012A0M1-SZ CC109101805
36 – 75 Vdc 1.8 V 12 A 85 SMT HW012A0Y1-S 108968397
36 – 75 Vdc 1.8 V 12 A 85 SMT HW012A0Y1-SZ 109100377
36 – 75 Vdc 2.5 V 10 A 89 SMT HW010A0G1-S 108968413
36 – 75 Vdc 3.3 V 10 A 90 SMT HW010A0F1-S 108967985
36 – 75 Vdc 3.3 V 10 A 90 SMT HW010A0F1-SZ 108995214
36 – 75 Vdc 5.0 V 6 A 91 SMT HW006A6A1-S 108968355
36 – 75 Vdc 5.0 V 6 A 91 SMT HW006A6A-S CC109142155
36 – 75 Vdc 5.0 V 6 A 91 SMT HW006A6A1-SZ 109100352
Option Suffix
Negative remote on/off logic 1
Approved for Basic Insulation –B
Surface mount interconnections –S
RoHS Compliant -Z
