Galaxy Power System 4848/100 with 595 Series Rectifiers S1:3 and later
Issue 10 February 2008 Specifications 9 - 7
AC Input Panels
Table 9-D: AC Panels
Vac AC Feeds Rectifiers ED83142-30 H569-434GPS4848/100
AC Circuit Breaker Panels - 595 Rectifiers
208/240 2 4 3 20, 220
208/240 2 6 4 21
480 1 4 2 22
480 2 6 4 23
65KIC 480 2 4 10 70, 270
65KIC 480 2 6 11 71
AC Terminal Strip Panels- 595 Rectifiers
208/240 4 4 5 24, 224
208/240 6 6 5 25
208/240 8 8 18 129, 131
480 4 4 5 26, 226
480 6 6 5 27
480 8 8 18 128, 130
Distribution Only Panels, no ac
- None 28
- None 29
Battery Connection Panels
Table 9-E: Battery Connection Panels
Fuse or
Circuit Breaker LVBD Shunt ED83143-31
H569-434
GPS4848/100
No Battery Panel
None 33
Panels without Fuses or Circuit Breakers
1,500A 30 32
2,000A 3,000A 36 39
1,200A 1,500A 31 31
2 x 500A 2 x 600A 32 30
Panels with Fuses or Circuit Breakers
2 x NH3 fuse
2 x 600A 41 34
1 x NH3 fuse 600A 42 35
2 x NH3 fuse 1,200A 2 x 600A 43 with 31 80
4 x NH3 fuse 1,200A 4 x 600A 2 x 43 with 31 81
6 x NH3 fuse 1,200A 6 x 600A 3 x 43with 31 82
6 x breaker poles 63 86
6 x breaker poles 800A 64 87
Off Line Equalize Panels
1,200A 3 x 1,000A 60 37
3 x 1,000A 61 38
