Galaxy Power System 4848/100 with 595 Series Rectifiers S1:3 and later
Issue 10 February 2008 List of Figures - 3
Figure 7-12: H569-434 G96 (ED83143-31 G15)
510A DC Distribution Panel 7-7
Figure 7-13: H569-434 G97 (ED83143-31 G16)
14-Position, and H569-434 G98 (ED83143-31 G17)
22-Position DC Distribution Panel 7-7
Figure 7-14: H569-434 G54 (ED83143-31 G54)
5-Position DC Distribution Panel 7-8
Figure 7-15: H569-434 G58 (ED83143-31 G58)
6-Position GMT DC Distribution Panel 7-8
Figure 11-1: Installing a Rectifier in a Rectifier Shelf 11-5
Figure 11-2: Fan Replacement 11-9
Figure 12-1: Location of Cabinet Alarm Light and
Controller 12-2
Figure 12-2: Millennium Controller Display 12-5
Figure 12-3: Millennium Controller Fuses and
Circuit Boards 12-5
Figure 12-4: Rectifier Display 12-6
Figure 12-5: Low Voltage Battery Disconnect Contactor
Control Switches 12-7
Figure 12-6: AC Input Panel and Rectifier Connection 12-8
Figure 12-7: DC Distribution Panel 12-9
Figure 12-8: Low Voltage Load Disconnect Contactor
Control Switches 12-10
