Galaxy Power System 4848/100 with 595 Series Rectifiers S1:3 and later
9 - 4 Specifications Issue 10 February 2008
Rectifiers
Table 9-B: 595 Series Rectifier Specifications - S1:3 and later
See Issue 8 for pre S1:3 specifications.
Electrical
Output Voltage 52Vdc typical
Equalize Voltage 65Vdc typical
Output Voltage Adjustment 44-58Vdc float/boost
58-65Vdc equalize mode
Regulation (with controller) ±0.5%
High Voltage Shutdown
(selected by controller) Float/boost 44-60Vdc (56Vdc default)
Equalize 44-67Vdc (65Vdc default)
Backup High Voltage Shutdown Float/boost 59-60Vdc (59.5Vdc nominal)
Equalize 65.5-66.5Vdc (66Vdc nominal)
Thermal Alarm
595A3 105°C
1
595B3 103°C 1
1
Internal rectifier component temperature
Ripple 100mVrms
Noise <2mV psophometric
Permanent Overload 220Adc
Current Limit Set Point 60Adc - 220Adc
(60Adc - 100Adc in equalize)
Nominal Input Voltage 595A3 Rectifier 380-480Vac, 3-wire plus ground
Nominal Input Voltage 595B3 Rectifier 200-240Vac, 3-wire plus ground
Input Voltage Range
595A3 Rectifier 595B3 Rectifier
320Vac - 530Vac 176Vac - 254Vac
Input Current
Specified
595A3 Rectifier 595B3 Rectifier
20A at 480Vac 40A at 208Vac
25A at 380Vac 35A at 240Vac
Rated Maximum 30A 50A
Typical Maxumum 23.7A at 320Vac 44.1A at 176Vac
16.2A at 480Vac 38.8A at 200Vac
20.4A at 380Vac 37.3A at 208Vac
32.3A at 240Vac
Typical Maximum
Rectifiers A3 / B3
S1:2 and prior
24.9A at 320Vac 45.3A at 176Vac
16.6A at 480Vac 39.9A at 200Vac
21.0A at 380Vac 38.3A at 208Vac
33.2A at 240Vac
Frequency Range 47 - 63 Hz
Power Factor >0.98 @ 50% to 100% load
Total Harmonic Distortion <5% @ 50% to 100% load
