Galaxy Power System 4848/100 with 595 Series Rectifiers S1:3 and later
Issue 10 February 2008 Rectifiers 4 - 1
4 Rectifiers
595 Series
Overview Two 200-ampere rectifiers are available for the GPS 4848/100 system:
595A Series and 595B Series. The 595A Series operates from 3-phase
ac service with a phase-to-phase voltage within the range of
320-530Vac. The 595B Series operates from 3-phase ac service with a
phase-to-phase voltage within the range of 170-260Vac.
The rectifiers are shipped separately from the cabinets for quick and
straightforward installation into rectifier shelves at the site.
Interconnections to ac input, dc output, and control signals occur
automatically during insertion. The rectifiers are keyed to prevent
installation of a rectifier with incompatible ac input. No operational
settings or adjustments to potentiometers are necessary. The installer
must set the rectifier’s ID using the ON/STBY switch to allow the
controller to learn the rectifier’s physical location for alarm reporting.
