Interface card DeviceNet
——————
6.2 SBI INFO MENU
The keypad display shows either general purpose useful information (card
address, current Baud Rate, etc.) or information about the communication states
(node status, allocation status, etc.), in order to allow a fast troubleshooting if
the card can not be connected to the bus.
SBI INFO
MAC ID
XX
Baud Rate
XXX kBit
Node status
X X X
Status of alloc.
S:X A:X M:XXX
CNXN status
PE:X PP:X UE:X
IO CNXN status
XXX
DUP.MAC ID TEST
"text"
reserved - 1
XXXXXXXXXXXXX
Software version
V. X.XXX
Compatib. index
V XX.XX DNM0040
By pressing the Cursor-Up/Cursor-Down keys it is possible to move through
the Menu items; the Cancel key allows to go back to the upper level Menus.
The first 8 information are automatically refreshed.
