0 devicenet function, 1 object description – GE Industrial Solutions 6KCV301DNET User Manual
Page 12
GEI-100435A
——————
Interface card DeviceNet
——————
12
3.0 DEVICENET FUNCTION
In this chapter are described the functions of DeviceNet managed by the SBI
card. The main characteristics of the card are:
1.
The card operates only as Slave in “Predifined Master/Slave Connection
Set”.
2.
Within the “Predefined Master/Slave Connection Set” the card is a “UCMM
Capable Device”.
3.
The “Explicit Messaging” is managed.
4.
The “Polling” for the fast cyclical data exchange Master/Slave is man-
aged.
5.
The detection mechanism of the “Duplicate MAC ID” is implemented.
Regarding the “Explicit Messaging” the fragmentation of the data frame, with
a total of max. 38 byte, is managed.
Connection sizes
CONNECTION INSTANCE
PRODUCED
CONSUMED
Polled I/O
Explicit messaging
38
38
tdn30020
Dependent on frame setting
