6 technical specification, 7 interface, 0 devicenet function – GE Industrial Solutions 6KCV301DNET User Manual
Page 11
6KCV301DNET
11
——————
Interface card DeviceNet
——————
2.6 TECHNICAL SPECIFICATION
Storage temperature:
-20°... +70°C (-68...+158°F)
Operating temperature:
0°... +55°C (32...+131°F)
Such temperatures are suitable to be used with those of the drive, which they
are connected to.
2.7 INTERFACE
For the mechanical connection, according to the internal or external mounting,
please use the kit and the mounting instruction sheet supplied with the card.
For the electrical connection please use the SBI-Drive link cable, also supplied.
For the connection to the Bus please use a shielded twisted cable recom-
mended by DeviceNet specification.
The connection among the single cards is accomplished by a shielded cable as
shown in the following figure:
6KCV301DNET
PE
Shield
6KCV301DNET
6KCV301DNET
