GEI-100435A
——————
Interface card DeviceNet
——————
14
Object Optional/Required # of Instances
Identity Required 1
Message Router Required 1
DeviceNet Required 1
Connection Required at maximum one Explicit
Assembly Optional 0..2
Drive Parameter Access Optional many
DGF Parameter Access Optional many
tdn0030ge
3.1.2 How Objects Affect Behavior.
The “Affect Behaviour” of the objects is reported in the following table:
Object Effect on Behavior
Identity Supports “Reset Service”.
Message Router No effect
DeviceNet Port attributes configuration
Connection Contains the number of logical ports
internal or external to the SBI board
Assembly Defines the I/O data format
Drive Parameter Access Drive parameters read/write
DGF Option Parameter Access DGF parameters read/write
tdn0040ge
3.1.3 Defining Object Interface
The object interface of the SBI card is the following:
Object Interface
Identity Message router
Message Router
Explicit Messaging
Connection Instance
DeviceNet Message router
Connection Message router
Assembly
I/O Connection or
Message Router
Drive Parameter Access Message router
DGF Parameter Access Message router
tdn0050ge
